NEWS (March 19th, 2013)
Presently we do not have an ETA  of when the MS-16 Mainstation will be available.   We will update the website when we  have more information.


Downloads
Brochure [PDF]
Owner's Manual - Rev A [PDF]


WARRANTY
2 Year Parts & Labor Limited Warranty




If you would like an email notification when the
MS-16 will be available for purchase,
please click here:
Your email address will only be used to notify
you regarding the MS-16's availability.








AM / FM/ Digital Radio / CD / USB / Bluetooth
The Mainstation is a user friendly in-wall audio system suitable for residential and commercial use.  Capable of driving 8 stereo pairs of speakers or 16 speakers in mono. It is ideal for residences doctor/dental offices, restaurants, tanning salons, shopping malls, etc.

Model Number: MS-16 In-Wall Audio System
  8 Pairs of 16 Mono Speakers
  (Not Suitable for Common Ground Speaker Wiring)
Power Requirements: 120VAC / 120 watts
  (Also available): 230VAC / 120 watts



UL Listed
IR Remote Control (included)
AM / FM / Digital Radio / CD / AUX / USB / Bluetooth
Multi-Function Digital Display Window
Digital Clock with Dual Alarms
Alarm with Snooze Function
Timer / Sleep Function
Side Loading CD slot
Tuner Memory Presets (30 AM & 30 FM)
AM / FM Auto Seek
Independent Bass & Treble Controls
Headphone 3.5mm Jack Output
Zone B Paging
Audio Muting
Intro Function
Programming to store the track in memory
ID3 MP3 Metadata Display
Mono or Stereo Operations
4 Digital Stereo Amplifiers
Energy Efficient
Available in White or Black Finish
New or Existing Construction
Unit Mounts in Standard 2" x 4" Stud Walls
Mounts directly to 16 "On-Centers Studs



Bluetooth
USB port for charging and audio playback
AUX input (RCA Jacks)
AM & FM Antenna inputs
Pre-Amp Outputs for driving external Power Amplifiers (RCA Jacks)
Speaker Outputs capable of driving up to 8 pair of 8 ohm speakers
without impedance compensating devices (2 ohms min. per channel)




Overall Dimensions: 16" x 10" x 2.7" deep
Face Dimensions: 14" x 8" x 1.3" deep
Cut-Out 14.5" x 8.5"

Shipping Dimensions: N/A
Shipping Weight: N/A
Net Weight:  N/A
